HMA 102 Dual Search Light Branch Signal (Red/Green) | N Gauge
The Search Light Branch Signal operates with two bi-polar LED’s which permanently oppose one another (meaning one light will display red while the other will display green, and vice versa).

Each signal contains a bi-polar LED in each socket that can be changed with a two way toggle switch (such as HMA 114) or via a point motor accessory switch (such as Peco PL-13 Accessory Switch or Turtoise/Cobalt Slow Action Motors).

This item is also available in OO/HO Gauge. Click here to see HMA 2102

Contents:
x1 HMA 102 Dual Search Light Branch Signal
x2 HMA 111 Diodes (IN4004)
Instruction Manual

12 Volts DC or 15 Volts AC power supply and toggle switch required. Setup in 10 minutes when following the instructions provided. These are fine scale signals and are not a toy. Handle with care for long life!

Purpose of Dual Search Light Branch Signal
These signals are placed near a junction to indicate route of travel.

UPPER SIGNAL is for Mainline Routing
LOWER SIGNAL is for Branchline Routing.
For example, if the junction is set for travel on the Mainline, the top signal will display GREEN with the bottom displaying RED. If the junction is set for travel on the Branchline, the top signal will display RED with the bottom displaying GREEN.
SKU HMA2102
Shipping Weight 0.6000kg
Shipping Width 0.250m
Shipping Height 0.250m
Shipping Length 0.250m
Shipping Cubic 0.015625000m3
Type HOBBIES-SCENICS
